Custom Heatsinks Design Process
If you do not have drawing, we can provide you custom heatsink design, our engineer need some information as below,
Custom heatsink size: Length, Width, and Height (mm)
The power the size of the heat source
The ambient temperature, the maximum temperature allowed by the chip
Estimated Annual Usage & budget
Thermal problem test & Simulation calculation
When finished costom heat sink design, our engineer make thermal problem test and simulation calculation by software as below.
Liquid cooling software: Ansys
Analytical software: Qfin
Structural mechanics software: Ansys
Rapid prototyping and test
We can make Rapid prototyping for your test and to check the quality and Thermal performance.Usually we delivery to you by express, Such as TNT, DHL, UPS, Fedex and so on. And then just waiting for you to confirm samples.
Mass production
1) Custom heatsink design and samples confirmed
2) Most of heat sink need make extrusion mould or stamping mould. May be need 15days
3) Buy heatsink materials and cooling components,
4) Process(Extruded, CNC machining, stamping, skiving, soldering)
5) Final inspection and packaging
It usually costs 25-35days for mass production.
Delivery: Sea/Air transportation
After finishing the mass production, we begin to arrange the delivery, Sea or Air transportation are both ok. The delivery time depends on which country are you from and the transportation way.
